Products
Power Plants
INDUSTRIAL POWER & PROCESS (IPP)
ATMOSPHERIC FLUIDISED BED COMBUSTION BOILER
| AFBC (WITH BED EVAPORATOR TUBES): | AFBC is a water tube boiler with Bidrum / Single Drum type configurations and under bed and/or over bed type of firing. Catering mainly to process and power applications with different fuel combinations particularly suitable for low volatile fuels like coal and lignite, husk etc. “Open bottom furnace” type can also be given which is suitable for high ash fuels like char, washery rejects (upto 50% with coal) etc. |
|---|---|
| Capacity : | 25 to 200 TPH |
| Pressure : | Upto 125kg/cm2 |
| SH Temperature : | 540OC |
| Application : | Power & Process |
BUBBLING FLUIDISED BED COMBUSTION BOILER
| BFBC (WITHOUT BED EVAPORATOR TUBES) : | Bidrum / Single drum configurations catering mainly to process and power applications with different fuel combinations of biomass fuels. This boiler is popular in Europe. Open bottom furnace type can also be given for some specific difficult fuels. |
|---|---|
| Capacity : | 25 to 200 TPH |
| Pressure : | Upto 125kg/cm2 |
| SH Temperature : | 540OC |
| Application : | Power & Process |
CIRCULATING FLUIDISED BED COMBUSTION BOILER
| CIRCULATING FLUIDISED BED COMBUSTION BOILER (CFBC) : | The Boiler is a Single drum hot cyclone/cold cyclone type configurations. Catering mainly to power applications with different fuel combinations particularly suitable for firing high volatile/ash/moisture fuels, very low CV fuels, nonconventional fuels etc., (100% Char, washery reject, petcoke, difficult biomass fuels). The efficiency of the boiler is high (around 88% on NCV) and due to complete combustion the ash will have low LOI that makes it suitable for cement production. |
|---|---|
| Capacity : | 25 to 200 TPH |
| Pressure : | Upto 125kg/cm2 |
| SH Temperature : | 540OC |
| Application : | Power & Process |
GRATE TYPE BOILER
| GRATE TYPE BOILER : | It is a conventional Grate boiler with Bidrum/single drum type. Flexibility in fuel firing is the main reason for the rising popularity of this type of boiler - from coal to bio-mass. Very popular for firing bagasse in sugar mills. Used for both the process and power applications. Pin hole, Dumping, Stepped reciprocating inclined, Flat water cooled vibrating grates etc., can be given for specific requirements/fuels. |
|---|---|
| Capacity : | 25 to 200 TPH |
| Pressure : | Upto 125kg/cm2 |
| SH Temperature : | 540OC |
| Application : | Power & Process |
NEW TYPE BOILERS
| The following New type of boilers are already developed/under development |
|---|
| |
| |
| |
| |
| |
| |
